Glass Tube Rotameter With One Flow Alarm Switch Adjustable Throughout Flow Range
Glass Tube Rotameter With One Flow Alarm Switch Adjustable Throughout Flow Range
Product Code: (SDG Series)
It is an instrument used to measure instant flow rate of Liquids and Gases. It is installed in the pipe line vertically upward with flanged or screwed connection.
Design & Calibration Conforms to ISA-RP16.5 & ISA-RP16.6
Specification:
| Fluid | : | Liquids & Gases |
| Density / Sp. Gravity | : | Up to 2.95 |
| Viscosity | : | Up to 200 cp |
| Design Temperature | : | Up to 150°C |
| Design Pressure | : | Up to 15 Kg/cm² Depending on Model |
| Measuring Range | : | 2.5 to 40,000 LPH of Water/Liquid & 0.1 to 750 Nm³/hr of Air/Gas at NTP |
| Line Size | : | Up to 4″ NB |
| Available Materials | : | MS/CS/SS304/SS304L/SS316/SS316L/PTFE lined MS or SS |
| Connection | : | Flanged to ASA/BS/DIN/ Triclover Standard Screwed to BSP/NPT(M/F) |
| Accuracy | : | ±2% of FSD & ±1.5% on request |
Glass Tube Rotameter With One Flow Alarm Switch Adjustable Throughout Flow Range
Glass Tube Rotameter With One Flow Alarm Switch Adjustable Thoughout Flow Range
Product Code SDFS1
Glass Tube Rotameter With High And Low Flow Alarm Switch Adjustable Thoughout Flow Range
Product Code SDFS2
Glass Tube Rotameter with TC End
Product Code SDG
Glass Tube Rotameter With Steam Jacket Arrangement
Product Code SDGSJ
Glass Tube Rotameter With Screwed Connection And Rear/Side Entry
Product Code SDG-RSC
Glass Tube Rotameter With Screwed Connection And Rear/Side Entry
Product Code SDG-VSC
Glass Tube Rotameter With Flanged Connection And Rear/Side Entry
Product Code SDGREF
