Float and Board Type Level Indicator

Float and Board Type Level Indicator

Product Code : FBLI6600

A totally new, reliable and accurate system for liquid level measurement in tall and overhead tanks.
Highly efficient and rugged in construction, this instrument is very suitable for large storage tanks for Water, Fire Water, DM Water, Oil, LSHS, Diesel, Lube Oil, Vegetable Oils, Molasses, Silicates, Glucose, All Non-Hazard, Non- Pressurised tanks.
As the liquid rises in the tank, the large float also goes up, in turn moving the pointer on the graduated scale. The float is connected to the pointer with the wire rope which glides over almost frictionless nylon rollers, thereby ensuring trouble free operation.

Specification

Tank height / Range : 0 to 10 mtrs Without Wire Rope Guide Assembley Above 10 mtrs With Wire Rope Guide Assembley
Temperature : Up to 150°C
Pressure : Up to 1 Kg/cm²
Connection : Flanged to ASA/BS/DIN/ Screwed BSP/NPT
Wetted Part Material : MS/CS/SS304/SS304L/SS316/SS316L/PP/HDPE/PVDF Lined/PTFE Lined
Float and Board Type Level Indicator
Float & Board Type Level Indicator
Float & Board Type Level Indicator
Product Code FBLI6600
Float & Board Type Level Indicator High & Low Level Switch
Float & Board Type Level Indicator High & Low Level Switch
Product Code FBLI6600-LS
Float & Board Type Level Indicator With Wire Rope Guide Assembley
Float & Board Type Level Indicator With Wire Rope Guide Assembley
Product Code FBLI8800
Float & Board Type Level Indicator With Wire Rope Guide Assembley and High & Low Level Switch
Float & Board Type Level Indicator With Wire Rope Guide Assembley and High & Low Level Switch
Product Code FBLI8800-LS
