By-Pass Metal Tube Rotameter
By-Pass Metal Tube Rotameter
Product Code : (BPC SDMT Series)
Suitable for measuring flow rates in 50 NB & above pipeline. Available in a variety of materials, carrier rings, impulse piping and rotameter as flow indicator.
Design Standard conforms to ISO 5167/BS 1042
Specification
| Fluid | : | Liquids, Gases & Steam |
| Density / Sp. Gravity | : | Up to 1.85 |
| Viscosity | : | Below 10 cp |
| DesignTemperature | : | Up to 150°C |
| Design Pressure | : | Up to 25 Kg/cm² in case of SDMT Series |
| Measuring Range | : | 22 to 300 M³/hr of Water /Liquid 0.1 to 800 Nm³/hr of Air/Gas at NTP |
| Line Size | : | 50 NB to 450 NB |
| Carrier Ring Materials | : | MS/CS/SS304/SS304L/SS316/SS316L/Monel/Hastalloy/PVC/PP |
| Connection | : | Carrier Ring suitable to mount between ASA/BS/DIN Flanges |
| Accuracy | : | ±2% of FSD & ±1.5% on request |
| Enclosure | : | Weather proof, IP-65 / Flame Proof |
By-Pass Metal Tube Rotameter
Horizontal Mounting By-Pass Glass Tube Rotameter With Carrier Ring
Product Code BPCSDGH
Horizontal Mounting By-Pass Metal Tube Rotameter With Carrier Ring
Product Code BPCSDMTH
Vertical Mounting By-Pass Metal Tube Rotameter With Carrier Ring
Product Code BPCSDMTV
Vertical Mounting By-Pass Metal Tube Rotameter With Carrier Ring, Flow Alarm Switch, 4-20mA Transmitter & Totalizer
Product Code BPCSDMTV-XT-TZ
Horizontal Mounting By-Pass Metal Tube Rotameter With Carrier Ring, 4-20 mA Transmitter & Totalizer
Product Code BPCSDMTH-XT-TZ
Horizonta Mounting By-Pass Metal Tube Rotameter With Carrier Ring & Flow Alarm Switch Adjustable Throughout Flow Range
Product Code BPCSDMTH-FS
